Yooj yim rau kev khiav lag luam vibration xeem lub rooj ntev zaum
Daim ntawv thov
Lub simulated tsheb thauj mus los vibration rooj, tseem hu ua "vibration table", yog siv los rov ua dua qhov kev puas tsuaj los ntawm pob thaum lub tsheb thauj mus los.Nws lub hom phiaj yog los txiav txim seb cov khoom puas tuaj yeem tiv taus ib puag ncig kev co.Lub simulated tsheb thauj mus los vibration xeem lub rooj ntev zaum ntsuam xyuas lub peev xwm ntawm ntau yam khoom nrog rau cov loads tshwj xeeb los tiv thaiv txoj kev tiag tiag thaum lub tsheb thauj mus los.Qhov no tso cai rau kev ntsuam xyuas qhov cuam tshuam ntawm cov xwm txheej tiag tiag ntawm cov khoom hauv chav kuaj, muab lub hauv paus rau kev ntsuam xyuas lossis kev pom zoo ntawm cov khoom thiab lawv cov ntim.Lub tshuab ntsuas no yog cov cuab yeej tseem ceeb rau kev txhim kho cov khoom zoo thiab kev ntseeg siab.
Lub thoob ntiaj teb advanced faib system mechanism system nrog 32-ntsis floating point DSP processor yog siv.Cov kev ua tau zoo ntawm kev co tswj qhov system yog ntxiv txhim kho.Modular thiab qis suab nrov
tsim thev naus laus zis, kev txhim kho ywj pheej hauv lub thawv tswj, kev sib txuas yooj yim nrog USB 2.0 thiab khoos phis tawj, Windows 8 raws li daim ntawv thov software, muaj hwj chim tswj software nrog kev tswj hwm kev tswj hwm algorithms.
High precision-microcomputer tus lej tswj lub sijhawm;digital display vibration rate xyuas.
Tsis tshua muaj suab nrov - synchronized nyob ntsiag to txoj siv sib hloov;DC lub cev muaj zog tsis pib;kev vibration zam roj hmab taw.
Yooj yim rau kev khiav lag luam - Aluminium profile swb rail clamping.
Yooj yim rau nruab thiab rhuav tshem-hnyav lub luag haujlwm steel chassis nrog kev co damping roj hmab hauv qab ncoo, tag nrho lub tshuab tsis tas yuav tsum tau kho, ua haujlwm zoo.
Tus nqi qis - txog ib feem tsib ntawm tus nqi ntawm cov khoom siv zoo sib xws hauv lwm lub tebchaws.
| Kev taw qhia ntawm kev vibration | Rotary (Khiav) |
| Kev ntsuas siab tshaj plaws | 200 kg |
| Kev vibration zaus (rpm) | 100 ~ 300 RPM tsis tu ncua adjustable |
| amplification | 1 nti (25.4 hli) ± 1.5% |
| cov txee | 0-999.99 h |
| Qhov loj ntawm lub rooj ua haujlwm | LxW (mm): 1400x1000mm |
| hnyav | Txog 580 kg |
| fais fab mov | 1 ∮, AC220V, 10A |
| Kev khiav hauj lwm lub sij hawm teem caij | 0～99H99/0～99M99/0～99S99 |
| Shaker Khoom | Stainless hlau |
| khoov (machining) | Aluminium |
| Digital ceev raug | Tsis ntau tshaj ± 3 rpm |
