Sand Thiab Dust Chamber
Daim ntawv thov
Nws pib qhov chaw plua plav pov thawj thiab plua plav tsis kam kuaj tshuab
Cov khoom siv no tsim nyog rau kev sim cov khoom siv hluav taws xob thiab hluav taws xob, tsheb thiab tsheb kauj vab thiab cov ntsaws ruaj ruaj hauv cov xuab zeb thiab plua plav ib puag ncig kom tiv thaiv cov xuab zeb thiab plua plav nkag mus rau hauv cov ntsaws ruaj ruaj thiab cov plhaub.Txhawm rau ntsuas qhov ua tau zoo ntawm cov khoom siv hluav taws xob thiab hluav taws xob, cov khoom siv tsheb thiab cov tsheb kauj vab thiab cov ntsaws ruaj ruaj hauv cov xuab zeb thiab plua plav ib puag ncig rau kev siv, khaws cia thiab thauj.
Lub hom phiaj ntawm qhov kev xeem yog los txiav txim siab qhov ua rau muaj kev phom sij ntawm cov khoom uas nqa los ntawm huab cua tam sim no ntawm cov khoom siv hluav taws xob.Qhov kev sim no tuaj yeem siv los simulate qhib huab cua ntawm cov xuab zeb thiab plua plav vim los ntawm ib puag ncig ntuj lossis los ntawm kev cuam tshuam ntawm tib neeg xws li kev txav tsheb.
| Qauv | KS-SC512 |
| Studio qhov ntev | 800 * 800 * 800mm (W * D * H) |
| Sab nraud chamber dimension | 1050 * 1250 * 2000 hli (W * D * H) |
| Plua plav qhov kub thiab txias | RT + 10 ℃ ~ 60 ℃ |
| hmoov av zoo | ua 75um |
| Cov hmoov av ntxhib | 150um los yog tsawg dua |
| Airflow ceev | Tsis ntau tshaj 2m / s |
| Plua plav concentration | 2 kg/m³ |
| Tus nqi ntawm talcum hmoov | 2-5 kgm 3 |
| Plua plav tshuab txoj kev | Los ntawm sab saum toj mus rau hauv qab |
| Cua flow meter | 1-20L / M |
| Negative siab sib txawv ntau yam | -10 ~ 0kpa tuaj yeem tsim kho tau |
| Hlau txoj kab uas hla | 50 awm |
| Nominal sib nrug ntawm cov xov hlau | 75um lossis tsawg dua 150um |
| Lub sijhawm poob siab | 1s rau 99h (kho tau) |
| Test lub sij hawm | 1s rau 99h (kho tau) |
| Plua plav tshuab tswj lub voj voog | 1s rau 99h (kho tau) |
| Lub sijhawm nqus tsev | 1s rau 99h (kho tau) |
| Controller tswj muaj nuj nqi | (1) Plua plav tshuab lub sij hawm (nres, tshuab) h / m / s adjustable |
| (2) Lub voj voog voj voog arbitrarily adjustable | |
| (3) Preset xeem lub sij hawm: 0s ~ 999h99m99s Arbitrarily adjustable | |
| (4) Fais fab ntawm hom: so - hla - so | |
| Cov kiv cua ncig | Lub cev muaj zog uas tsis muaj suab nrov.Multi-lobe centrifugal ntxuam |
| Load-bearing | 10kg ua |
| Saib qhov rais | 1 |
| Teeb pom kev zoo | 1 |
| Tswj qhov system piv txwv fais fab qhov (sockets). | Plua plav pov thawj AC220V 16A |
| Tswj systems | PLC tswj + kov npo (kesionots) |
| Lub tshuab nqus tsev vacuum | Siab regulator, suction nozzle, siab regulator teeb peb, txuas raj, lub tshuab nqus tsev twj |
| Plua plav cua sov system | Stainless hlau mica ntawv cua sov tsho |
| Cov khoom siv sab hauv chamber | SUS201 stainless hlau daim iav phaj |
| Cov khoom siv sab nrauv chamber | A3 hlau phaj nrog electrostatic txau kho |
